Product details
Ecutee floor transmission jack 200kg – 185–590mm, 4 swivel castors
This transmission jack takes the faff out of lifting and lowering gearboxes, propshafts and differentials. It’s straightforward, dependable and designed for anyone wanting steady, controlled support when lining up or removing transmission parts. Ideal for home mechanics and light workshop work.
Key features
Don’t be fooled by the compact footprint — this jack is well thought-out and saves time. The hand-operated scissor lift gives you fingertip control over height, so you can nudge a gearbox into place without too much messing about. The saddle comes with a ratcheting, non-marking strap and a small 5° tilt to help when the angles are being awkward. Four heavy-duty 76mm swivel castors make it a doddle to manoeuvre around the garage, even on slightly uneven floors.
- 200kg rated capacity — suits many small to medium gearboxes and differential units
- Height range 185–590mm — works for low-profile cars and higher-clearance tasks
- Saddle strap secures the load and stops it slipping while you fine-tune the position
- Operated via a 1/2″ square drive adaptor — uses standard drive tools you’ll already have
- Stable 420 x 400mm base keeps the load balanced during lift and lower
Technical specifications
- Capacity: 200kg
- Lifting height: 185–590mm
- Base dimensions: 420 x 400mm
- Castor diameter: 76mm
- Drive socket size: 1/2″ sq. dr.
- Saddle type: fixed with ratcheting non-marking strap (5° tilt)
- Weight: 18.5kg
- Model: 09021
Practical uses and benefits
When a gearbox needs lowering or coaxing into place, this jack removes the guesswork. It’s a proper help for clutch changes, gearbox swaps or diff removals on smaller cars. The hand lift gives gradual, controlled movement — no sudden drops and less chance of nicking expensive parts. It’s light enough to slide under a ramp or tuck into a tight corner, yet robust enough for regular use in a home garage.
Common questions
What if I’m unsure about the capacity? Always check the gearbox weight before lifting — 200kg covers many smaller units but won’t do for heavy truck gearboxes.
Will it work with my tools? Yes — it uses a 1/2″ square drive adaptor, so your familiar drive tools will operate it.
Is it workshop-ready? Yes. Use it on a level surface and give the strap a quick check before every job — a bit of simple maintenance keeps things safe.
All in all, the Ecutee transmission jack gives you precise control without faff. It’s not a heavy-duty hydraulic trolley for massive loads, but for gearbox work where accuracy matters, it’s a tidy, well-balanced choice. No more relying on guesswork under the car — this makes the job neater and quicker.
